SBCHE61K5J
Through Hole Resistor, 1.5 kohm, SBC Series, 7 W, ± 5%, Axial Leaded, 102.5 V
Többre van szüksége?
| Mennyiség | |
|---|---|
| 1+ | 575,100 Ft |
| 5+ | 477,900 Ft |
| 10+ | 379,080 Ft |
| 20+ | 299,295 Ft |
| 40+ | 267,300 Ft |
| 100+ | 235,305 Ft |
Termékinformáció
Termékáttekintés
The TE Connectivity SBC (Square Ceramic) series are through hole, power wirewound resistors. These resistors are wound on continuous glass fibre elements or have a ceramic core depending on resistance value. The element is housed in a ceramic case and sealed with inorganic silica filler. Their construction gives a resistor with high insulation resistance and low surface temperature, capable of withstanding high overload currents. These resistors are ideally suited to a variety of applications within industrial and commercial environments where performance and reliability are of prime importance. The SBC series resistors are mainly used in fan force ovens, cooker hoods, power supplies and triac based speed control applications.
- Resistance value ranges from 0.2ohm to 22Kohm
- Maximum power rating of 17W
- Available in ±5% and ±10% tolerance
- Temperature coefficient is 200ppm/°C (400ppm/°C below 18ohm)
- Operating temperature range -55°C to +350°C
- Vertical or axial mounting style
- Fusible style, non flammable
- Special solvent resistance
- High Power Resistor
Műszaki adatok
1.5kohm
7W
Axial Leaded
Wirewound
High Power
38mm
-55°C
-
SBC Series
± 5%
102.5V
± 200ppm/°C
-
8mm
350°C
No SVHC (14-Jun-2023)
Műszaki dokumentumok (1)
Jogszabályok és környezetvédelem
Az ország, amelyben az utolsó jelentősebb gyártás történt meg.Származási ország:India
