Találja meg a(z) Panel / Chassis Mount Resistors széles választékát a(z) Farnell Magyarország áruházban. A(z) Panel / Chassis Mount Resistors termékek nagy választékát kínáljuk, beleértve a világ vezető gyártóinak új és legnépszerűbb termékeit, köztük a következőket: TE Connectivity - Cgs, Ohmite, Arcol, TT Electronics / Welwyn & Multicomp Pro

Gyártói cikkszám	Rendelési kód	Gyártó / Leírás	Adott egységre meghatározott ár	Ár (ÁFA nélkül)	Resistance	Product Range	Power Rating	Resistor Case / Package	Resistance Tolerance	Resistor Terminals	Voltage Rating	Resistor Technology	Temperature Coefficient	Resistor Type	Resistor Mounting	Product Length	Product Width	Product Height	Operating Temperature Min	Operating Temperature Max	Qualification

RCH25S4R700JS06	1141502 Data Sheet RoHS Date/Lot Code	VISHAY Resistor 4.7 ohm RCH Series 25 W ± 5% Solder Lug 550 V	Each	1+6 343,583 Ft 3+5 856,716 Ft 5+5 738,580 Ft	4.7ohm	RCH Series	25W	-	± 5%	Solder Lug	550V	Thick Film	± 150ppm/°C	High Power	Panel Mount	28mm	27.5mm	15mm	-55°C	125°C	-
SH506R800JS03	1141236 Data Sheet RoHS Date/Lot Code	VISHAY Resistor 6.8 ohm SH Series 50 W ± 5% Solder Lug 1.285 kV	Each	1+2 838,861 Ft 10+2 258,917 Ft 100+1 632,434 Ft	6.8ohm	SH Series	50W	-	± 5%	Solder Lug	1.285kV	Wirewound	± 50ppm/°C	High Power	Panel Mount	50mm	29.4mm	15mm	-55°C	200°C	-
HSA50R47J	3399731 Data Sheet RoHS Date/Lot Code	TE CONNECTIVITY - CGS Resistor Solder Lug 0.47 ohm HS Series 50 W ± 5% Solder Lug 1.25 kV	Each	1+2 688,505 Ft 5+2 301,876 Ft 10+1 990,424 Ft 20+1 553,677 Ft 40+1 457,019 Ft További árak…	0.47ohm	HS Series	50W	-	± 5%	Solder Lug	1.25kV	Wirewound	± 50ppm/°C	High Power	Chassis Mount	51mm	30mm	17mm	-	-	-
HSA1047RJ	2058956 Data Sheet RoHS Date/Lot Code	TE CONNECTIVITY - CGS Resistor Solder Lug 47 ohm HS Series 16 W ± 5% Solder Lug 265 V	Each	1+1 646,754 Ft 5+1 585,896 Ft 10+1 027,431 Ft 25+962,993 Ft 50+945,094 Ft	47ohm	HS Series	16W	-	± 5%	Solder Lug	265V	Wirewound	± 50ppm/°C	High Power	Panel Mount	21mm	21mm	11mm	-	-	-
SQBW3015RJFASTON	2805367 Data Sheet RoHS	TE CONNECTIVITY - CGS Resistor 15 ohm SQ Series 30 W ± 5% Quick Connect	Each	1+1 725,512 Ft 3+1 331,723 Ft 5+1 238,645 Ft 10+1 141,988 Ft 20+988,052 Ft További árak…	15ohm	SQ Series	30W	Radial Leaded	± 5%	Quick Connect	-	Wirewound	± 300ppm/°C	High Power	Panel Mount	-	-	-	-55°C	250°C	-
HS25 10R J	2478168 Data Sheet RoHS	ARCOL Resistor Axial Leaded 10 ohm HS Series 25 W ± 5% Solder Lug 550 V	Each	1+1 091,870 Ft 3+902,135 Ft 5+859,176 Ft 10+816,217 Ft 20+719,560 Ft További árak…	10ohm	HS Series	25W	-	± 5%	Solder Lug	550V	Wirewound	± 100ppm/°C	High Power	Panel Mount	27.3mm	28mm	14.8mm	-	-	MIL-PRF-18546
RHA00510R00FE02	3976480 Data Sheet RoHS Date/Lot Code	VISHAY Resistor 10 ohm RHA Series 7.5 W ± 1% Solder Lug	Each	1+2 319,775 Ft 10+1 596,635 Ft	10ohm	RHA Series	7.5W	-	± 1%	Solder Lug	-	Wirewound	± 20ppm/°C	-	Chassis Mount	28.58mm	16.41mm	8.13mm	-55°C	250°C	AEC-Q200
CJP150J68RJ	4048926 Data Sheet RoHS	TE CONNECTIVITY - CGS Resistor 68 ohm CJP Series 150 W ± 5% Radial Leaded 850 V	Each	1+12 787,403 Ft 10+10 464,048 Ft	68ohm	CJP Series	150W	-	± 5%	Radial Leaded	850V	Wirewound	± 200ppm/°C	High Power	Chassis Mount	215mm	40mm	20mm	-25°C	250°C	-
XV2 10R J	4307774 Data Sheet RoHS	DURAKOOL Resistor 10 ohm XV2 Series 70 W ± 5% 1.5 kVDC	Each	1+3 096,614 Ft 5+2 656,286 Ft 10+2 445,072 Ft 20+2 223,118 Ft 40+2 051,283 Ft További árak…	10ohm	XV2 Series	70W	-	± 5%	-	1.5kVDC	Metal Wirewound	± 220ppm/°C	High Power	-	75mm	33.5mm	-	-40°C	155°C	-
CJP150J100RJ	4048927 Data Sheet RoHS	TE CONNECTIVITY - CGS Resistor 100 ohm CJP Series 150 W ± 5% Radial Leaded 850 V	Each	1+12 787,403 Ft	100ohm	CJP Series	150W	-	± 5%	Radial Leaded	850V	Wirewound	± 200ppm/°C	High Power	Chassis Mount	215mm	40mm	20mm	-25°C	250°C	-
RHA0102K000FE02	3976511 Data Sheet RoHS Date/Lot Code	VISHAY Resistor 2 kohm RHA Series 12.5 W ± 1% Solder Lug	Each	1+1 410,481 Ft 10+959,413 Ft	2kohm	RHA Series	12.5W	-	± 1%	Solder Lug	-	Wirewound	± 20ppm/°C	-	Chassis Mount	34.93mm	20.32mm	9.91mm	-55°C	250°C	AEC-Q200
MPQLJ0221C50	4069015 Data Sheet RoHS Date/Lot Code	MULTICOMP PRO Resistor 220 ohm MP QL Series 2.5 kW ± 5% Solder Lug	Each	1+40 832,339 Ft 2+36 321,665 Ft 3+31 481,641 Ft 5+30 221,516 Ft	220ohm	MP QL Series	2.5kW	-	± 5%	Solder Lug	-	Wirewound	± 300ppm/°C	Power	Chassis Mount	600mm	60mm	119mm	-55°C	155°C	-
XV1-30 1K J B	4307757 Data Sheet RoHS	DURAKOOL Resistor Bracket 1 kohm XV1 Series 30 W ± 5% Solder Lug 1.5 kVDC	Each	1+2 326,935 Ft 5+1 994,004 Ft 10+1 836,489 Ft 25+1 754,151 Ft 50+1 668,233 Ft	1kohm	XV1 Series	30W	-	± 5%	Solder Lug	1.5kVDC	Ceramic Wirewound	± 220ppm/°C	High Power	Panel Mount	74mm	19mm	20mm	-40°C	155°C	AEC-Q200
RHA02510R00FE02	3976521 Data Sheet RoHS Date/Lot Code	VISHAY Resistor 10 ohm RHA Series 25 W ± 1% Solder Lug	Each	1+1 782,790 Ft	10ohm	RHA Series	25W	-	± 1%	Solder Lug	-	Wirewound	± 20ppm/°C	-	Chassis Mount	49.23mm	27.43mm	13.87mm	-55°C	250°C	AEC-Q200
CJH2000J82RJ	4048558 Data Sheet RoHS	TE CONNECTIVITY - CGS Resistor 82 ohm CJH Series 2 kW ± 5% Radial Leaded 850 VDC	Each	1+59 852,348 Ft	82ohm	CJH Series	2kW	-	± 5%	Radial Leaded	850V	Wirewound	± 200ppm/°C	High Power	Chassis Mount	400mm	103mm	52mm	-25°C	250°C	-
XV2 30R J	4307776 Data Sheet RoHS	DURAKOOL Resistor 30 ohm XV2 Series 70 W ± 5% 1.5 kVDC	Each	1+3 096,614 Ft 5+2 656,286 Ft 10+2 445,072 Ft 20+2 223,118 Ft 40+2 051,283 Ft További árak…	30ohm	XV2 Series	70W	-	± 5%	-	1.5kVDC	Metal Wirewound	± 220ppm/°C	High Power	-	75mm	33.5mm	-	-40°C	155°C	-
CJP300J680RJ	4048977 Data Sheet RoHS Date/Lot Code	TE CONNECTIVITY - CGS Resistor 680 ohm CJP Series 300 W ± 5% Radial Leaded 850 V	Each	1+15 690,702 Ft	680ohm	CJP Series	300W	-	± 5%	Radial Leaded	850V	Wirewound	± 200ppm/°C	High Power	Chassis Mount	215mm	60mm	30mm	-25°C	250°C	-
RHA01010R00FE02	3976495 Data Sheet RoHS	VISHAY Resistor 10 ohm RHA Series 12.5 W ± 1% Solder Lug	Each	1+1 363,942 Ft 10+923,614 Ft	10ohm	RHA Series	12.5W	-	± 1%	Solder Lug	-	Wirewound	± 20ppm/°C	-	Chassis Mount	34.93mm	20.32mm	9.91mm	-55°C	250°C	AEC-Q200
CJP600J220RJ	4049037 Data Sheet RoHS Date/Lot Code	TE CONNECTIVITY - CGS Resistor 220 ohm CJP Series 600 W ± 5% Radial Leaded 850 V	Each	1+25 918,476 Ft	220ohm	CJP Series	600W	-	± 5%	Radial Leaded	850V	Wirewound	± 200ppm/°C	High Power	Chassis Mount	335mm	60mm	30mm	-25°C	250°C	-
RHA010560R0FE02	3976509 Data Sheet RoHS Date/Lot Code	VISHAY Resistor 560 ohm RHA Series 12.5 W ± 1% Solder Lug	Each	1+1 363,942 Ft 10+923,614 Ft	560ohm	RHA Series	12.5W	-	± 1%	Solder Lug	-	Wirewound	± 20ppm/°C	-	Chassis Mount	34.93mm	20.32mm	9.91mm	-55°C	250°C	AEC-Q200
MPQLJ0330050	4068941 Data Sheet RoHS Date/Lot Code	MULTICOMP PRO Resistor 33 ohm MP QL Series 50 W ± 5% Solder Lug	Each	1+2 742,203 Ft 2+2 065,602 Ft 3+1 736,252 Ft 5+1 503,558 Ft 10+1 381,841 Ft	33ohm	MP QL Series	50W	-	± 5%	Solder Lug	-	Wirewound	± 300ppm/°C	Power	Chassis Mount	102mm	28mm	61mm	-55°C	155°C	-
CJP200J1R0J	4048936 Data Sheet RoHS	TE CONNECTIVITY - CGS Resistor 1 ohm CJP Series 200 W ± 5% Radial Leaded 850 V	Each	1+13 807,674 Ft	1kohm	CJP Series	200W	-	± 5%	Radial Leaded	850V	Wirewound	± 200ppm/°C	High Power	Chassis Mount	165mm	60mm	30mm	-25°C	250°C	-
CJP60J1R5J	4048852 Data Sheet RoHS Date/Lot Code	TE CONNECTIVITY - CGS Resistor 1.5 ohm CJP Series 60 W ± 5% Radial Leaded 850 V	Each	1+7 234,978 Ft 3+6 980,805 Ft 5+6 726,632 Ft 10+5 756,479 Ft 20+5 641,922 Ft	1.5ohm	CJP Series	60W	-	± 5%	Radial Leaded	850V	Wirewound	± 200ppm/°C	High Power	Chassis Mount	115mm	40mm	20mm	-25°C	250°C	-
MPQLJ0681050	4068947 Data Sheet RoHS Date/Lot Code	MULTICOMP PRO Resistor 680 ohm MP QL Series 50 W ± 5% Solder Lug	Each	1+2 742,203 Ft 2+2 065,602 Ft 3+1 736,252 Ft 5+1 503,558 Ft 10+1 381,841 Ft További árak…	680ohm	MP QL Series	50W	-	± 5%	Solder Lug	-	Wirewound	± 300ppm/°C	Power	Chassis Mount	102mm	28mm	61mm	-55°C	155°C	-
CJH3000J47RJ	4048573 Data Sheet RoHS Date/Lot Code	TE CONNECTIVITY - CGS Resistor 47 ohm CJH Series 3 kW ± 5% Radial Leaded 850 VDC	Each	1+73 796,059 Ft 5+71 966,730 Ft	47ohm	CJH Series	3kW	-	± 5%	Radial Leaded	850V	Wirewound	± 200ppm/°C	High Power	Chassis Mount	400mm	103mm	52mm	-25°C	250°C	-
